Non-Standard Custom Parameter Filling Area:

Basic Requirements:
State Of The Material To Be Crushed: Material, Volume, Weight, Etc.
Output Size Requirements (Unit: Mm):
Productivity (Unit: Kg):
Other Requirements:

FY-H4040

Cutter head diameter	Φ400mm
Thickness of cutter head	20mm~80mm
Output speed	0~15rpm
Hydraulic motor displacement	About (8100ml/r)*2
Rated pressure	16Mpa
Maximum pressure	20Mpa
Rated torque	About (18000NM)*2
Maximum torque	About (22000NM)*2

FY-H6066

Cutter head diameter	Φ620mm
Thickness of cutter head	30mm~100mm
Output speed	0~10rpm
Hydraulic motor displacement	About (22000ml/r)*2
Rated pressure	16Mpa
Maximum pressure	20Mpa
Rated torque	About (50000NM)*2
Maximum torque	About (61000NM)*2

FY-H6066

Cutter head diameter	Φ880mm
Thickness of cutter head	80mm~160mm
Output speed	0~8rpm
Hydraulic motor displacement	About (66000ml/r)*2
Rated pressure	16Mpa
Maximum pressure	20Mpa
Rated torque	About (150000NM)*2
Maximum torque	About (180000NM)*2
